ISO API N80 Float Shoe with Carbon Steel or 304 Stainless Steel Construction and 1 Year Warranty for Well Drilling

Carbon Steel Float Shoe

304 Stainless Steel Float Shoe

1 Year Warranty Float Shoe

원래 장소:

중국

인증:

API ISO

연락주세요

인용문을 요구하세요

ISO API N80 Float Shoe with Carbon Steel or 304 Stainless Steel Construction and 1 Year Warranty for Well Drilling

제품 상세정보

무게:

5kg

밸브 유형:

단일 밸브 및 이중 밸브

기계 유형:

드릴링 도구

처리 유형:

단조

재료:

탄소강 / 304 스테인레스 강

크기:

5 1/2 ", 7", 9 5/8 ", 13 3/8"

보어 OD:

6 ", 7 5/8", 10 5/8 ", 14 3/8"

구멍 ID:

4 3/4 ", 6 1/4", 8 5/8 ", 12 3/8"

최소 보어:

2 ", 2 3/8"

스레드 유형:

5 1/2 "LCSG, 7"LCSG, 9 5/8 "LCSG, 13 3/8"LCSG

압력 등급:

4351, 3626 lb/in2

핵심 구성 요소:

판막

모크:

1 세트

용법:

유전 드릴링 장비

해당 산업:

에너지 및 광업

API Standard 114.3mm Float Shoe and Float Collar with 150°C and 204°C Seals for Oilfield Drilling

최상의 가격을 얻으세요

API Standard Nose Float Shoe Cementing Float Equipment with 150°C and 204°C Seals for Oilfield Drilling

최상의 가격을 얻으세요

API 5CT 7-5/8" L80 BTC/LTC Eccentric Multiple Flank Jets Aluminum Alloy Float Shoe for Cementing Tool

최상의 가격을 얻으세요

Customizable API 5CT High Pressure Double Plug Cementing Head with 35MPa Working Pressure and 1 Year Warranty

최상의 가격을 얻으세요

연락주세요

86-519-83553967

Leo@service-js.com

86-519-83553967

지금 접촉하세요

제품 설명

ISO API N80 BTC/LTC Squagging Cementing Float Shoe with Single or Double Valve

Float equipment serves as the backbone of casing equipment used during primary cementing operations. Float equipment guides the casing to total depth and prevents contaminated mud from entering the casing. It also provides a landing point for casing wiper plugs, reinforces the lower end of the casing string, and ensures precise cement slurry displacement.

Specifications

Name	Size (in)	Bore O.D. (in)	Bore I.D. (in)	Min Bore Parameter (in)	Thread Type	lb(in²)
Float Collar	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
Float Shoe	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
